Bently Nevada 330103-00-07-10-02-00 3300 XL 8mm Proximity Probe

What It Is

A small, tough sensor for checking machine vibration in factories or workshops. Made by Bently Nevada, it’s built to work reliably in tight spaces with its 1-meter design.

Model Number: Broken Down

330103: Basic 8mm probe (M10x1 thread, no extra armor)
00: No unthreaded part (0mm)
07: Case length (70mm – outer body size)
10: Total length (1.0m / 3.3ft – full sensor length)
02: Connector type (small ClickLoc + standard cable)
00: No special safety approvals needed

Key Features

Measure range: 2mm (80 mils) – works from 0.25mm (10 mils) to 2.3mm (90 mils)
Resistance: 7.59Ω ±0.50Ω (for 1m length – stable signal)
Temp range: Works from -52°C to +177°C (-62°F to +350°F). Tip handles up to +218°C (+425°F).
Cable max: 305m (1,000ft) between probe and monitor

What It’s Made Of

Tip: PPS plastic (strong, heat-resistant)
Case: Stainless steel (AISI 303/304 – rust-proof)
Seal: Viton O-ring (keeps pressure in check)
Weight: 323g/m (11.4oz) – light but sturdy

Safety Info

Safe in explosive areas (ia): Class I Zone 0 (Groups A-D), Class II (Groups E-G)
Safe in non-explosive areas (nA/ec): Class I Zone 2 (Division 2, Groups A-D)

Install Tips

Use 3-wire shielded cable (0.2-1.5mm² / 16-24 AWG)
Tin wires for better connections
Keep above -34°C (-30°F) to protect seals

Works With

Pairs with 3300 XL Proximitor Sensors.

What’s Included

1x 330103-00-07-10-02-00 proximity probe unit.
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
