Bently Nevada 330103-00-07-05-02-CN 3300 XL 8mm Proximity Probe

What It Does

A durable sensor for industrial vibration checks. Made by Bently Nevada, it works well in tough spots like factories or machinery rooms.

Model Code Explained

330103: Base 8mm probe (M10x1 thread, no armor)
00: No unthreaded part (0mm)
07: Case length (7mm)
05: Total length (0.5m / 1.6ft)
02: Connector type (small coaxial ClickLoc with standard cable)
CN: Country-specific safety approvals

Key Specs

Measure Range: 2mm (80 mils), from 0.25mm (10 mils) to 2.3mm (90 mils)
Resistance: 7.45Ω ±0.50Ω (for 0.5m length)
Temp Range: Standard: -52°C to +177°C (-62°F to +350°F); Extended tip: -52°C to +218°C (-62°F to +425°F)
Cable Limit: Up to 305m (1,000ft) between probe and monitor

Build & Materials

Tip: PPS (tough plastic)
Case: Stainless steel (AISI 303/304)
Thread: M10x1, max 15mm fit
Weight: 323g/m (11.4oz)
Sealing: Viton O-ring (seals pressure between tip and case)

Safety Ratings

Safe for explosive areas (ia): Class I Zone 0, Groups A-D; Class II Groups E-G
Safe for non-explosive areas (nA/ec): Class I Zone 2, Division 2 Groups A-D

Install Tips

Use 3-wire shielded cable (0.2-1.5mm² / 16-24 AWG)
Tin wires for better connection
Keep above -34°C (-30°F) to protect seals

Works With

Pairs with 3300 XL Proximitor Sensors for easy setup.

What’s Included

1x 330103-00-07-05-02-CN proximity probe unit.
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
