Bently Nevada 8mm Vibration Probe – Model 330102-00-32-10-01-00

Easy-to-use vibration sensor for machines. Has 1-meter cable and safe connector cover. Works in very hot or cold places (-52°C to +177°C).

Main Features

• Strong plastic tip (PPS material)
• Metal case (stainless steel)
• Special seal (Viton® O-ring)
• Secure connector with cover
• 1 meter cable length

Key Numbers

• Brand: Bently Nevada
• Type: 8mm Vibration Probe
• Full Code: 330102-00-32-10-01-00
• Measures: 0.25-2.3mm movement
• Best distance: 1.27mm from target
• Works from: -52°C to +177°C
• Screw size: 3/8-24 UNF

What The Numbers Mean

How To Install

• Works with 9 meter sensors (when using 3m version)
• Max wire length: 305 meters
• Use thick wires (16-24 AWG)
• Don’t use below -34°C
• Works in wet air

Safety Approvals

• Safe for dangerous areas
• Approved for many machine types

What’s In The Box

• 1 vibration probe
• Connector with cover
• 1 meter cable

Where To Use

• Big spinning machines
• Air compressors
• Power generators
• Water pumps
• Electric motors

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
