Bently Nevada 3300 XL 8mm Industrial Vibration Probe
Core Specifications
- Precision Measurement: 0.25mm to 2.3mm range
- Temperature Resilience: -52°C to +218°C operation
- Output Signal: 7.87V/mm ±3% accuracy
- Cable Strength: 330N pull resistance
- Material: Stainless steel body with PPS tip
Model Number Breakdown
330101-00-20-10-01-CN
- ├── 00: Zero unthreaded length
- ├── 20: 2.0″ (50.8mm) case length
- ├── 10: 1.0m (3.3ft) cable length
- ├── 01: ClickLoc connector with protector
- └── CN: China market approval
Enhanced Technical Data
- Frequency Response: 0-12kHz
- Humidity Resistance: 93% RH for 56 days
- Cable Capacitance: 70pF/m ±5%
- Vibration Resistance: 20g peak
- Pressure Seal: Viton® O-ring
- Weight: 323g/m (0.7lb/ft)
Installation Guide
- Mount with 3/8-24 UNF thread
- Maintain 1.27mm air gap
- Use shielded 18AWG triad cable
- Max 305m field wiring
Application Scenarios
- ▶ Gas turbine monitoring
- ▶ Centrifugal compressors
- ▶ High-speed pumps
- ▶ Power generation
- ▶ Paper mill machinery
- ▶ Marine propulsion
What’s Included
- ✓ Vibration probe assembly
- ✓ Protected ClickLoc connector
- ✓ Installation manual
- ✓ Compliance documentation
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
