21000-34-10-20-062-04-02 Bently Nevada Proximity Probe Housing Assembly

Bently Nevada 21000-34-05-15-29-04-02 Proximity Probe Housing Assembly

Key Technical Specifications

• Brand & Model: Bently Nevada 21000 with complete suffix code 21000-34-10-20-062-04-02.
• Probe Option: 34 = 3300 XL 8 mm probe with connector protector with selectable hazardous area approvals.
• Probe Cable Length: 10 = 1.0 meter (39 inches).
• Standoff Adapter: 20 = 0.2 inch.
• Probe Penetration: 062 = 6.2 inches.
• Fitting Option: 04 = one 3/4-14 NPT plug only.
• Mounting Thread: -02 = 3/4-14 NPT (required when standoff adapter is not -00).
• Material: Aluminum body with 304 stainless steel sleeve.
• Maximum (C) + (D) with visible probe: 17.0 inches (43.18 cm).
• Maximum (C) + (D) total dimension: 32.9 inches (83.5 cm).
• Weight: 1.1 kg (2.4 lb) typical without fittings.
• Approvals & Compliance: CSA Type 4 enclosure, explosion-proof for hazardous areas, and fully compliant with API 670 Standard.
• Environmental Protection: O-rings and thread seals provide reliable sealing in industrial environments.

Frequently Asked Questions (FAQ)

• Q: Is the 21000 housing intrinsically safe?
  A: Yes, you can order hazardous area approved probes with this housing for intrinsically safe applications. CSA certifications apply.
• Q: What is the exact standoff adapter length on this model?
  A: The suffix code 20 specifies a 0.2 inch standoff adapter.
• Q: What is the probe penetration depth?
  A: Code 062 gives you 6.2 inches of probe penetration.
• Q: Can I use this housing outdoors in wet conditions?
  A: Yes, the CSA Type 4 enclosure rating makes it suitable for wet or dusty locations.
• Q: Is this assembly fully API 670 compliant?
  A: Yes, Bently Nevada designed the 21000 and 24701 housings to meet API 670 Standard for externally mounted proximity probes.
• Q: How long until you ship?
  A: We ship within 5 days via FedEx, UPS, or DHL.
• Q: What if I need to return the product?
  A: We offer a simple 30-day return window. The unit must remain in original condition.
