140NWM10000 Modicon Quantum D10 Ethernet Module Schneider

140NWM10000 – Modicon Quantum Class D10 Ethernet TCP/IP Module with FactoryCast HMI Active

Key Technical Specifications

• The 140NWM10000 provides an Ethernet TCP/IP interface with Modbus TCP messaging.
• It includes an SNMP agent for simple network management protocol services.
• This module supports both MT/RJ fiber optic (10BASE-T/100BASE-TX) and RJ45 twisted pair (100BASE-FX) physical interfaces.
• Transmission rate reaches 10 or 100 Mbit/s with auto-negotiation capability.
• Local signaling includes LEDs for data rate, collision, kernel mode, fault, network status, full duplex, ready, link, active, and TxAct/RxAct.
• Current consumption stays at 750 mA from a 5 V DC supply via the rack’s power system.
• Operating ambient temperature ranges from 32 °F to 140 °F (0 °C to 60 °C).
• Storage temperature tolerates -40 °F to 185 °F (-40 °C to 85 °C).
• Relative humidity withstands 95 % without condensation.
• Operating altitude reaches up to 14763.78 feet (4500 meters).
• Electrostatic discharge resistance meets 4 kV contact and 8 kV on air per IEC 801-2.
• Electromagnetic field resistance achieves 9.1 V/m (10 V/m) from 80 to 1000 MHz per IEC 801-3.
• IP20 protection rating suits standard industrial environments.
• Product certifications include cUL, UL 508, FM Class 1 Division 2, and CSA C22.2 No 142.

Frequently Asked Questions (FAQ)

• Q1: Is the 140NWM10000 a new original module?
  Yes, we supply only new and original 140NWM10000 modules.
• Q2: Do you have the 140NWM10000 in stock?
  Yes, we keep the 140NWM10000 in stock for immediate orders.
• Q3: What is the typical shipping time for this module?
  We ship all orders within 5 business days after payment confirmation.
• Q4: Which couriers do you use for delivery?
  We ship via FedEx, UPS, or DHL depending on your location.
• Q5: Can I return the 140NWM10000 if it does not fit my system?
  Yes, we support returns within 30 days from delivery date.
• Q6: Does the 140NWM10000 support both fiber and copper connections?
  Yes, it features both MT/RJ fiber optic and RJ45 twisted pair ports.
• Q7: What communication protocols does this module use?
  It uses Modbus TCP/IP and SNMP agent protocols for network communication.
• Q8: Can I use this module for web-based HMI applications?
  Yes, the FactoryCast HMI active feature enables web server and data editor functions.
• Q9: What do the LEDs indicate during operation?
  LEDs show network speed, collision, fault, duplex mode, link status, and transmission activity.
• Q10: Is this module compliant with international standards?
  Yes, it meets cUL, UL 508, FM Class 1 Division 2, and CSA C22.2 No 142 standards.
