Modicon Quantum 140ESI06210 – ASCII Serial Link Module

Key Technical Specifications

• Brand & Model: Schneider Electric – 140ESI06210 (Modicon Quantum series).
• Number of ports: 2 RS232C non-isolated ports (DIN 66020).
• Electrical connection: 2 SUB-D 9 connectors.
• Transmission rate: 19.2 kbit/s for reliable data exchange.
• Maximum cable distance: Up to 20 m between devices.
• Message nesting: 8 levels for complex communication.
• Buffer size: 255 input bytes and 255 output bytes.
• Number of messages: 255 messages supported.
• Message length: 127 characters maximum plus 1 checksum.
• Clock: Includes a calendar clock for time-stamped data.
• Memory capacity: 128 kB flash and 32 kB RAM.
• Power dissipation: 2 W maximum.
• Addressing requirement: 12 output words and 12 input words.
• Bus current requirement: 300 mA.
• Module format: Standard size for Quantum backplane.
• Software compatibility: Works with Concept V2, ProWORX 32 V2, ProWORX NxT V2, and Unity Pro V2.

Environmental Specifications

• Operating temperature: 0…60 °C (32…140 °F).
• Storage temperature: -40…85 °C (-40…185 °F).
• Humidity: 95% without condensation.
• Max altitude: 5000 m (16404 ft).
• EM field resistance: 10 V/m from 80 to 1000 MHz (IEC 801-3).

Installation Guide

• Product compatibility: Works with all Quantum CPUs.
• Application type: Designed for standard ASCII communication tasks.
• Transmission mode: ASCII protocol for simple text-based data.
• Mounting format: Standard module fits directly into Quantum backplane.
• Addressing: Requires 12 input words and 12 output words for configuration.
• Memory: 128 kB flash stores firmware. 32 kB RAM handles runtime data.

Frequently Asked Questions

• How many serial ports does this module have?
  It provides 2 RS232C ports for connecting ASCII devices.
• What is the maximum transmission speed?
  The 140ESI06210 supports up to 19.2 kbit/s.
• How many messages can it store?
  It handles up to 255 messages with 127 characters each.
• Does it have a real-time clock?
  Yes, it includes a calendar clock for time-stamped operations.
• What software works with this module?
  It works with Concept V2, ProWORX 32 V2, ProWORX NxT V2, and Unity Pro V2.
• Is it compatible with all Quantum CPUs?
  Yes, it works with all Quantum CPU models.
• What is the maximum cable length?
  You can run cables up to 20 m between devices.
• Is it brand new?
  Yes, we sell only brand new, factory-sealed units.
• How fast do you ship?
  We ship within 5 days using FedEx, UPS, or DHL.
• Where can I get the manual?
  Email us to get the PDF manual with wiring and configuration steps.
