140EIA92100 AS-Interface Master Module | Schneider 30V DC

Modicon Quantum 140EIA92100 – AS-Interface Master Module

Key Technical Specifications

• Brand & Model: Schneider Electric – 140EIA92100 (Modicon Quantum series).
• AS-i version: V1 with M2 profile.
• Transmission rate: 167 kbit/s for reliable data exchange.
• Maximum cycle time: 5 ms for fast response.
• Bus length: Up to 100 m without repeater.
• Discrete inputs: 124 total from connected slaves.
• Discrete outputs: 124 total from connected slaves.
• Slave devices supported: Up to 31 per master.
• Modules per PLC: 2 per distributed drop, 4 per local or remote drop.
• Power supply: Via AS-Interface line at 30 V DC.
• Current consumption: ≤ 100 mA, typical 60 mA at 30 V DC.
• Reverse polarity protection: Built-in for safety.
• Electrical connection: 1 male SUB-D 3-pin connector for AS-Interface link.
• Local signaling: 32 LEDs show slave addresses and I/O status.
• Marking: CE approved.

Environmental Specifications

• Operating temperature: 0…60 °C (32…140 °F).
• IP rating: IP20 for protection in control cabinets.
• Certifications: UL, CSA, FM, GOST, C-tick.
• Country of origin: France (FR).

Frequently Asked Questions

• How many slaves can this master support?
  It supports up to 31 AS-Interface slave devices.
• What is the maximum cycle time?
  The cycle time is 5 ms for fast I/O updates.
• How many I/O points does it handle?
  The 140EIA92100 supports 124 discrete inputs and 124 discrete outputs.
• What power does it need?
  It receives power via the AS-Interface line at 30 V DC. Current draw is ≤ 100 mA.
• Can I use this in a remote drop?
  Yes, it works in local, remote, and distributed Quantum drops.
• What certifications does it hold?
  It has UL, CSA, FM, GOST, C-tick, and CE mark.
• Is it brand new?
  Yes, we sell only brand new, factory-sealed units.
• How fast do you ship?
  We ship within 5 days using FedEx, UPS, or DHL.
• Where can I get the manual?
  Email us to get the PDF manual with wiring and setup steps.
