140DVO85300 Schneider Electric Output Module 0.5A Quantum Series

Schneider Electric 140DVO85300 Modicon Quantum Discrete Output Module Overview

Output Specifications and Electrical Characteristics

• Brand & Series: Manufactured by Schneider Electric for the Modicon Quantum automation platform.
• Output Configuration: Provides 32 discrete outputs arranged in 4 groups of 8 channels with negative sink logic.
• Voltage Range: Operates at 10…30V DC nominal with absolute maximum tolerance of 50V for 1s decaying pulse.
• Current Capacity: Supports 0.5A per point, 4A per group, and 16A total module current maximum.
• Voltage Drop: Maintains less than 0.4V voltage drop at 0.5A load for efficient power delivery.
• Surge Current: Handles 2.5A surge current for 1ms during demanding switching operations.

Protection Features and Fault Diagnostics

• Short-Circuit Protection: Includes integrated short-circuit protection on all output channels for system safety.
• Overvoltage Protection: Features comprehensive output overvoltage protection against voltage transients.
• Group Fusing: Provides internal output protection with 5A fuse per group for reliable fault isolation.
• Fault Indication: Detects incorrect output state, loss of field power, and blown fuse conditions.
• Load Inductance: Supports inductive loads with maximum inductance calculated as H = 0.5/(I² × F) for 0.5…4Hz.

Performance Characteristics and Response Times

• Response Time: Delivers ≤2ms turn-on and turn-off time for reliable signal processing.
• Fast Switching: Achieves 1ms response time for both state transitions in optimized conditions.
• Addressing Requirement: Requires 2 output words and 2 input words for complete configuration within the Quantum rack.
• Tungsten Load Rating: Supports 2.5W at 10V, 3W at 12V, and 6W at 24V for tungsten lamp loads.
• Power Dissipation: Dissipates 2.5W plus 0.1W per active point and 0.4W per total load current amp.

Environmental Specifications and Certifications

• Hazardous Location: Certified FM Class 1 Division 2 for use in potentially explosive industrial environments.
• Marine Approval: Holds RMRS certification for maritime and offshore applications requiring rugged reliability.
• Temperature Range: Operates reliably in 0 to 60°C (32 to 140°F) ambient industrial environments.
• EMC Immunity: Withstands 4kV contact ESD and 8kV air discharge per IEC 801-2 standards.
• Field Resistance: Resists electromagnetic fields of 10V/m from 80 to 2000 MHz per IEC 801-3.
• Altitude Rating: Suitable for installation at altitudes up to 5000m (16404 ft) without performance degradation.

Frequently Asked Questions (FAQ)

• Q: What is the exact model number for this Modicon Quantum output module?
  A: The module is the Schneider Electric 140DVO85300 with 32 DC output channels.
• Q: What output logic does the 140DVO85300 use?
  A: This module uses negative sink logic operating at 10…30V DC nominal voltage.
• Q: What is the maximum current per channel?
  A: The 140DVO85300 supports 0.5A per point with 4A per group and 16A total module current.
• Q: Does this module include short-circuit protection?
  A: Yes, the module features integrated short-circuit protection and overvoltage protection on all channels.
• Q: What fault detection capabilities does it have?
  A: It detects incorrect output state, loss of field power, and blown fuse conditions with red LED indication.
• Q: How quickly do you ship the 140DVO85300 module?
  A: We process and dispatch orders within 5 days via DHL, UPS, or FedEx carriers.
• Q: What is the return policy for this Schneider Electric output module?
  A: We offer 30-day returns on all brand new original automation components.
• Q: What certifications does this module hold?
  A: The 140DVO85300 holds FM Class 1 Div 2, RMRS, GOST, C-tick, UL 508, and CSA C22.2 No 142 approvals.
