140DSI35300 24V DC Input Module 32 Channels Schneider Electric

140DDO84300 Schneider Electric Modicon Quantum Wide Voltage Output Module

Main Technical Specifications

• Brand & Series: Schneider Electric manufactures this module for the Modicon Quantum series. It integrates seamlessly with existing systems.
• Wide Voltage Range: The 140DDO84300 operates on 10-60 V DC (10.2 to 72 V limits). It accepts up to 72 V permanently for demanding applications.
• Output Configuration: It provides 16 outputs in 2 groups of 8. It uses positive logic (source) for standard industrial control.
• Power Ratings: Maximum current is 12 A per module and 6 A per group. It handles surge current up to 7.5 A for 50 seconds.
• Speed: This module switches in ≤ 1 ms both on and off. Voltage drop stays below 1 V at 2 A load.
• Protection Features: Each group includes an 8 A fuse for safety. Each point has a 2 A fuse rating for reliable protection.
• High Isolation: It provides 2500 Vrms isolation between channels and the bus. Group isolation is 700 Vrms for 1 minute.
• LED Indicators: The front panel shows 16 green LEDs for output status. One green LED indicates bus activity, and one red LED shows faults.
• Environmental Resistance: It withstands 4 kV contact discharge and 8 kV air discharge. It operates from 0 to 60 °C.
• Power Consumption: The 140DDO84300 draws 160 mA from the bus. Total dissipation is 1 W plus 1 V x total load current.

Frequently Asked Questions

• Is this 140DDO84300 brand new?
  Yes, we sell brand new original Schneider Electric modules. The 140DDO84300 comes sealed in original factory boxes.
• What voltage range does this module support?
  The 140DDO84300 supports 10-60 V DC. It accepts up to 72 V DC permanently for added safety margin.
• What logic type does this module use?
  The 140DDO84300 uses positive logic (source). This means it switches the positive side of the load.
• Do you have this module in stock?
  Yes, we maintain stock of the Modicon Quantum 140DDO84300. We can ship immediately.
• What are your shipping methods?
  We ship within 5 days. We use FedEx, UPS, or DHL based on your location.
• Does it include fuse protection?
  Yes, each group has an 8 A fuse. Each output point has a 2 A fuse rating.
• What is the isolation rating?
  It offers 2500 Vrms isolation between channels and the bus. This is higher than standard Quantum modules.
• What is the return policy?
  We accept returns within 30 days. The 140DDO84300 must remain in new condition.
• Can this drive high-current loads?
  Yes, it handles 2 A continuous per point with surge capacity up to 7.5 A for 50 seconds.
• What do the red and green LEDs indicate?
  Green LEDs show individual output status. The red LED lights up for external faults or blown fuses.
