140DRC83000 Schneider Electric Modicon Quantum 8-Channel Relay Output

Schneider Electric 140DRC83000 Modicon Quantum Relay Output Module Overview

Contact Configuration and Electrical Ratings

• Brand & Series: Manufactured by Schneider Electric for the Modicon Quantum automation platform.
• Output Configuration: Provides 8 discrete relay outputs with 1 normally open and 1 normally closed contact per channel, Form C type.
• Voltage Flexibility: Supports 20…250V AC, 30…150V DC, and 5…30V DC for comprehensive application coverage.
• High Current Capacity: Handles 5A resistive load at 250/30V AC/DC up to 60°C, with 3A continuous rating for general use.
• Surge Protection: Includes internal varistor protection at 275V to suppress output voltage transients effectively.
• Switching Capacity: Delivers 1250VA resistive switching capacity with 20A surge current for 10ms capacitive loads.

Performance Specifications and Durability

• Response Time: Features 10ms turn-on time (0 to 1) and 20ms turn-off time (1 to 0) maximum.
• Mechanical Life: Rated for 10 million mechanical cycles, ensuring exceptional longevity in high-use applications.
• Electrical Durability: Achieves 200,000 cycles at 5A 250V AC resistive and 100,000 cycles at 5A 30V DC resistive.
• Switching Frequency: Supports 30Hz resistive switching and inductive switching calculated as F = 0.5/I²L.
• Isolation Ratings: Provides 1780Vrms AC isolation between channels and bus for 1 minute, plus 2500V DC.

Marine Certifications and Environmental Tolerance

• Marine Approvals: Holds ABS, DNV, GL, RINA, and RMRS certifications for maritime and offshore applications.
• Hazardous Location: Certified FM Class 1 Division 2 for use in potentially explosive industrial environments.
• Temperature Range: Operates reliably in 0 to 60°C (32 to 140°F) ambient industrial environments.
• EMC Immunity: Withstands 4kV contact ESD and 8kV air discharge per IEC 801-2 standards.
• Field Resistance: Resists electromagnetic fields of 10V/m from 80 to 2000 MHz per IEC 801-3.

Frequently Asked Questions (FAQ)

• Q: What is the exact model number for this Modicon Quantum relay module?
  A: The module is the Schneider Electric 140DRC83000 with 8 Form C relay outputs.
• Q: What contact configuration does the 140DRC83000 use?
  A: Each of the 8 channels uses 1 normally open and 1 normally closed contact with Form C configuration.
• Q: What is the maximum current rating for this relay output module?
  A: The module supports 5A resistive load at 250/30V AC/DC at 60°C ambient temperature.
• Q: Does this module have marine certifications?
  A: Yes, the 140DRC83000 holds ABS, DNV, GL, RINA, and RMRS approvals for marine use.
• Q: How quickly do you ship the 140DRC83000 module?
  A: We process and dispatch orders within 5 days via DHL, UPS, or FedEx carriers.
• Q: What is the return policy for this Schneider Electric output module?
  A: We offer 30-day returns on all brand new original automation components.
• Q: Can this module switch both AC and DC loads?
  A: Yes, the 140DRC83000 handles 20-250V AC, 30-150V DC, and 5-30V DC applications.
