140DDO36400 Modicon Quantum 96-Point Sink Module 24V DC

140DDO36400 Schneider Electric Modicon Quantum 96-Point Output Module

Main Technical Specifications

• Brand & Series: Schneider Electric manufactures this module for the Modicon Quantum series. It integrates seamlessly with existing systems.
• High-Density Outputs: The 140DDO36400 provides 96 outputs in 6 groups of 16. It uses negative logic (sink) for ground-switching applications.
• Power Ratings: It operates on 24 V DC (19.2 to 30 V range). Maximum current is 0.5 A per point, 3.2 A per group, and 19.2 A per module.
• Fast Response: This module switches in ≤ 0.1 ms both on and off. It handles surge current up to 2 A.
• Protection Features: It includes short-circuit protection and overload protection per point. This ensures reliable operation in demanding environments.
• Diagnostics: The module provides fault sensing and fault reporting. It identifies loss of field power and specific fault points.
• LED Indicators: The front panel shows 96 green LEDs for output status. One green LED indicates bus activity, and one red LED shows external faults.
• Environmental Resistance: It withstands 4 kV contact discharge and 8 kV air discharge. It operates from 0 to 60 °C.
• Power Consumption: The 140DDO36400 draws 250 mA from the bus. Total dissipation is 7 W.

Frequently Asked Questions

• Is this 140DDO36400 brand new?
  Yes, we sell brand new original Schneider Electric modules. The 140DDO36400 comes sealed in original factory boxes.
• How many outputs does this module have?
  The 140DDO36400 has 96 discrete outputs. This makes it ideal for high-density control applications.
• What logic type does this module use?
  The 140DDO36400 uses negative logic (sink). This means it switches the ground side of the load.
• Do you have this module in stock?
  Yes, we maintain stock of the Modicon Quantum 140DDO36400. We can ship immediately.
• What are your shipping methods?
  We ship within 5 days. We use FedEx, UPS, or DHL based on your location.
• Does it include overload protection?
  Yes, the 140DDO36400 includes both short-circuit protection and output overload protection per point.
• What is the return policy?
  We accept returns within 30 days. The 140DDO36400 must remain in new condition.
• How fast does this module switch?
  It switches in ≤ 0.1 ms both on and off. This makes it suitable for high-speed applications.
• What do the red and green LEDs indicate?
  Green LEDs show individual output status. The red LED lights up for external faults or fault conditions.
