140DDO35310 Schneider Electric Quantum Sink Output Module

140DDO35310 Schneider Electric Modicon Quantum Sink Output Module

Main Technical Specifications

• Brand & Series: Schneider Electric manufactures this module for the Modicon Quantum series. It integrates seamlessly with existing systems.
• Output Configuration: The 140DDO35310 provides 32 outputs in 4 groups of 8. It uses negative logic (sink) for ground-switching applications.
• Power Ratings: It operates on 24 V DC (19.2 to 30 V range). Maximum current is 16 A per module and 4 A per group.
• Speed & Surge: This module switches in ≤ 1 ms both on and off. It handles surge current up to 5 A for 1 ms.
• Protection Features: Each group includes a 5 A fuse for safety. It provides 1780 Vrms isolation between channels and the bus.
• LED Indicators: The front panel shows 32 green LEDs for output status. One green LED indicates bus activity, and one red LED shows faults.
• Environmental Resistance: It withstands 4 kV contact discharge and 8 kV air discharge. It operates from 0 to 60 °C.
• Power Consumption: The 140DDO35310 draws 330 mA from the bus. Total dissipation is 2.0 W plus load losses.

Frequently Asked Questions

• Is this 140DDO35310 brand new?
  Yes, we sell brand new original Schneider Electric modules. The 140DDO35310 comes sealed in original factory boxes.
• What logic type does this module use?
  The 140DDO35310 uses negative logic (sink). This means it switches the ground side of the load.
• Do you have this module in stock?
  Yes, we maintain stock of the Modicon Quantum 140DDO35310. We can ship immediately.
• What are your shipping methods?
  We ship within 5 days. We use FedEx, UPS, or DHL based on your location.
• Does it include fuse protection?
  Yes, each group has a 5 A fuse. Each output point also has a 3 A fuse rating.
• What is the return policy?
  We accept returns within 30 days. The 140DDO35310 must remain in new condition.
• What do the red and green LEDs indicate?
  Green LEDs show individual output status. The red LED lights up for external faults or blown fuses.
• Can this drive tungsten loads?
  Yes, it supports tungsten loads up to 12 W at 24 V.
