140DDO35301 Schneider Electric Quantum Discrete Output Module

140DDO35301 Schneider Electric Modicon Quantum Output Module

Main Technical Specifications

• Brand & Series: Schneider Electric makes this module for the Modicon Quantum series. It fits existing systems perfectly.
• Output Details: The 140DDO35301 offers 32 outputs in 4 groups of 8. It uses positive logic (source) for standard control.
• Power Ratings: It runs on 24 V DC (19.2 to 30 V range). Maximum current is 16 A per module and 4 A per group.
• Speed: This module switches fast. It takes ≤ 0.1 ms to turn off and ≤ 1 ms to turn on.
• Protection: Each group has a 5 A fuse for safety. It also isolates channels with 1780 Vrms from the bus.
• LED Indicators: The front shows 32 green LEDs for output status. One green LED shows bus activity, and one red LED shows faults.
• Environment: It resists 4 kV contact discharge and 8 kV air discharge. It works from 0 to 60 °C.
• Power Use: The 140DDO35301 draws 330 mA from the bus. It dissipates 5 W of power during use.

Frequently Asked Questions

• Is this 140DDO35301 brand new?
  Yes, we sell brand new original Schneider Electric modules. The 140DDO35301 comes sealed in original factory boxes.
• What voltage does this module use?
  The 140DDO35301 uses 24 V DC. It accepts 19.2 to 30 V DC for stable operation.
• Do you have this module in stock?
  Yes, we keep stock of the Modicon Quantum 140DDO35301. We can ship quickly.
• How do you ship and how fast?
  We ship within 5 days. We use FedEx, UPS, or DHL based on your location.
• Does it have fuse protection?
  Yes, each group has a 5 A fuse. Each point also has a 3 A fuse rating.
• Can I return this item?
  Yes, we accept returns within 30 days. The 140DDO35301 must be in new condition.
• What do the LEDs show?
  Green LEDs show output status. A red LED lights up for external faults or blown fuses.
