140DDO35300 Schneider Electric Quantum 24V DC Output Module

140DDO35300 Schneider Electric Modicon Quantum 24V DC Output Module

• Brand: Schneider Electric manufactures this module for the Modicon Quantum series.
• Model: The 140DDO35300 has 32 DC outputs arranged in 4 groups of 8 channels.
• Current Rating: Each group handles up to 4 A. The whole module handles up to 16 A total. Each point has a 3 A fuse.
• Protection: It includes internal output protection with 5 A fuses per group. LEDs show fault and active status clearly.

Technical Specifications

• Power Supply: The 140DDO35300 works with 19.2 to 30 V DC input. Voltage drop stays below 0.4 V at 0.5 A load.
• Isolation: It provides 1780 Vrms isolation between channels and bus. Group isolation is 500 Vrms DC for one minute.
• Temperature Range: It operates from 32 to 140 °F (0 to 60 °C). It stores from -40 to 185 °F (-40 to 85 °C).
• Speed: Response time is ≤ 1 ms for both on and off states. Surge current reaches 5 A for 0.5 ms.
• Certifications: It holds marine certifications including DNV, GL, ABS, BV, RMRS, and RINA. It also meets UL 508 and CSA standards.

FAQ

• What voltage does the 140DDO35300 use? It uses 24 V DC nominal power. Input range is 19.2 to 30 V DC.
• Is this module marine certified? Yes, it has DNV, GL, ABS, BV, RMRS, and RINA certifications. It works well in marine environments.
• Is this a new original part? Yes, we sell only new original Schneider Electric parts. The 140DDO35300 comes from our factory stock.
• When do you ship? We keep this Modicon Quantum module in stock. We ship all orders within 5 days.
• What shipping do you use? We ship with FedEx, UPS, and DHL. These carriers provide fast and safe delivery worldwide.
• Can I return it? Yes, you can return it within 30 days. The module must be in its original packaging and condition.
• Does it have fuse protection? Yes, it has 3 A fuses per point and 5 A fuses per group. This protects your system from overloads.
