140DDO15310 Schneider Electric Quantum 32 Output

140DDO15310 Schneider Electric Modicon Quantum Output Module

• Brand: Schneider Electric makes this module for the Modicon Quantum series.
• Model: The 140DDO15310 has 32 TTL output points in 4 groups of 8 channels.
• Output Power: Each point handles up to 75 mA. Each group handles up to 600 mA. The whole module handles up to 2.4 A.
• Protection: It has internal fuse protection and transient voltage suppression. LEDs show fault and status clearly.

Technical Specifications

• Power Supply: The 140DDO15310 needs 4 to 5.5 V DC input. It gives 500 Vrms isolation between groups for one minute.
• Temperature Range: It works from 32 to 140 °F (0 to 60 °C). It stores from -40 to 185 °F (-40 to 85 °C).
• Speed: Response time is ≤ 250 µs for both on and off states. Surge current reaches 750 A for 0.5 ms.
• Power Use: It dissipates 4 W of power. It draws 350 mA from the bus and 2800 mA at 5 V DC.
• Weight: The module weighs 0.45 kg (0.99 lb). Package size is 31.2 x 4.5 x 16.3 cm.

FAQ

• What voltage does the 140DDO15310 use? It uses 4 to 5.5 V DC power. State 1 voltage stays at or below 0.2 V.
• Is this a new original part? Yes, we sell only new original Schneider Electric parts. The 140DDO15310 comes from our factory stock.
• When do you ship? We keep this Modicon Quantum module in stock. We ship all orders within 5 days.
• What shipping do you use? We ship with FedEx, UPS, and DHL. These carriers give fast and safe delivery.
• Can I return it? Yes, you can return it within 30 days. The module must be in its original state and box.
• Does it have protection? Yes, it has internal fuse protection. Each point max is 75 mA. Each group max is 600 mA.
