140DDI35300 32-Channel 24V DC Discrete Input Schneider Electric

140DDI35300 Schneider Electric Quantum 32-Point 24V DC Input Module

The 140DDI35300 from Schneider Electric provides reliable 24V DC input for Modicon Quantum systems. This module handles 32 inputs in four groups with positive sink logic. Engineers choose the 140DDI35300 for its wide voltage range and robust industrial performance.

Key Technical Specifications

• Brand: Schneider Electric for Modicon Quantum platforms.
• Inputs: 32 DC inputs in 4 groups using positive logic (sink).
• Voltage: Works at 24 V DC nominal. Range is 19.2 to 30 V DC.
• Logic Levels: State 1 guaranteed from 15 to 30 V DC. State 0 from -3 to 5 V DC.
• Current: State 1 draws >= 2 mA. State 0 draws <= 0.5 mA.
• Impedance: Input impedance is 2500 Ohm for reliable signal reading.
• Protection: Input protection by resistor limiting. Max continuous input is 30 V.
• Speed: Turns on and off in 1 ms for fast response.
• Isolation: 1780 Vrms between group and bus. 500 Vrms between groups.
• Power: Dissipates 1.7 W plus 0.36 W per active point.
• LEDs: 32 green input status lights plus Active and Fault LEDs.
• Certifications: Meets CSA, UL, DNV, RINA, RMRS, BV, GOST, and ABS standards.

Frequently Asked Questions (FAQ)

• Is this 140DDI35300 brand new?
  Yes. We sell only brand new original Schneider Electric modules.
• Do you have this module in stock?
  Yes. We keep stock ready to ship right away.
• How fast do you ship?
  We ship within 5 days after order confirmation.
• Which shipping companies do you use?
  We use DHL, FedEx, and UPS for fast delivery.
• Can I return this item?
  Yes. You can return items within 30 days in original condition.
• What voltage does this input module use?
  It uses 24 V DC nominal with a range of 19.2 to 30 V DC.
• What is the response time?
  It responds in 1 ms for both on and off transitions.
• What logic type does this module use?
  It uses positive sink logic for the 32 input channels.
