140DAO84210 Schneider Electric AC Output Module 16ch 83‑253V

Schneider Electric 140DAO84210 AC Output Module – 16 Channels 83‑253V AC with Group Isolation

Key Technical Specifications

• ◆ Brand & Series: Schneider Electric Modicon Quantum – 140DAO84210 belongs to the trusted Quantum family.
• ◆ Output Channels: 16 discrete AC outputs in 4 isolated groups (4 channels per group).
• ◆ Output Voltage Range: 83‑253V AC, 47‑63Hz.
• ◆ Load Current: Up to 4A per output (85‑132V) or 3A per output (170‑253V); module total 16A rms; group limit 4A rms continuous.
• ◆ Surge Capability: Per point: 30A for 1 cycle, 20A for 2 cycles, 10A for 3 cycles; per group: 45A for 1 cycle, 30A for 2 cycles, 25A for 3 cycles.
• ◆ Off‑State Leakage: Very low leakage: 2mA @115V, 2.5mA @230V.
• ◆ Isolation & Protection: 4 groups of 4 channels (1000Vrms between groups). Internal RC filter and 5A fuse per group; dv/dt 400V/µs.
• ◆ Response Time: Ultra‑fast ≤0.5ms turn‑on and turn‑off.
• ◆ Diagnostics: 16 green output status LEDs, plus green Active LED and red Fault LED; blown fuse and loss of field power indication.
• ◆ Power & Weight: Bus current 350mA; dissipation 1.85W + (1.1V x total load current). Net weight 0.45kg (0.99lb).

Isolation, Environmental Tolerance & Compliance

• ◆ Group Isolation: Four groups of four outputs each, isolated to 1000Vrms, reducing noise coupling and simplifying wiring.
• ◆ Wide Ambient Range: Certified for operation from 0°C to 60°C and storage from -40°C to 85°C, withstanding 95% relative humidity without condensation.
• ◆ EMC / Immunity: Meets IEC 801‑2/‑3 standards: 4kV contact / 8kV air discharge and 10V/m radiated immunity (80‑1000MHz).
• ◆ Approvals: UL 508, CSA C22.2 No 142, cUL, and FM Class 1 Division 2 suitable for hazardous locations.
• ◆ Altitude: Safe for installation up to 5000m (16404ft).

Frequently Asked Questions (FAQ)

• Q: What is the main difference between 140DAO84210 and the fully isolated 140DAO84000?
  A: The 140DAO84210 groups outputs into four isolated groups of four, whereas 140DAO84000 provides individual channel isolation. This offers a cost‑effective solution when group isolation is sufficient.
• Q: What are the per‑group current limits?
  A: Each group of four channels supports up to 4A rms continuous, with the total module current not exceeding 16A rms.
• Q: How does the module indicate a blown fuse or loss of field power?
  A: The red Fault LED (F) illuminates, and specific group fault conditions are signalled via the front‑panel diagnostics.
• Q: What is the off‑state leakage current at 230V?
  A: Maximum leakage is only 2.5mA rms at 230V, ensuring minimal power draw when outputs are off.
• Q: Can I mix different AC voltages across the four groups?
  A: Yes, each group is isolated, so you can supply different voltages (e.g., 115V and 230V) to different groups as long as they stay within 83‑253V AC.
• Q: Does the 140DAO84210 support fast‑switching applications?
  A: Absolutely. With ≤0.5ms turn‑on and turn‑off times, it suits high‑speed AC switching tasks.
