140DAI54300 Schneider Electric 115V AC 16-Point Input Module

140DAI54300 Schneider Electric 115V AC 16‑Point Input Module, 2 Groups

This 140DAI54300 from Schneider Electric works with Modicon Quantum systems. It handles 115 V AC signals. The module gives you 16 input points split into two isolated groups. Bright LEDs show the status of each channel. This design offers flexible wiring and easy checks.

Key Technical Facts

• Brand & Model: Schneider Electric 140DAI54300 – a genuine Modicon Quantum VAC input module with two isolated groups.
• Voltage & Current: It runs on 115 V AC. The ON state starts at 79 V AC. OFF state is below 20 V AC. It draws 11.1 mA at 60 Hz.
• Speed & Frequency: It works with 47 to 63 Hz networks. Turn‑on time is 4.9 to 7.3 ms. Turn‑off time is 7.3 to 12.3 ms.
• Protection & Isolation: Two channel groups are isolated to 1780 Vrms. Leakage current stays below 2.1 mA. It can handle 200 V for one cycle.
• Tough Environment: It works from 0 °C to 60 °C. It resists humidity up to 95 % without condensation. It also handles electrical noise and static shocks.
• Power & Size: It uses 180 mA from the bus. Max heat output is 5.5 W. The module is light, just 0.3 kg.
• LEDs & Safety: 16 green LEDs show input status. One green LED shows bus power. One red LED shows faults. It meets UL 508 and CSA standards.

Frequently Asked Questions

• Is this module new and real? Yes, we sell only 100 % genuine Schneider Electric 140DAI54300 modules. They come sealed from the factory.
• Do you have the 140DAI54300 in stock? Yes, we keep good stock of this 115 V AC module with two groups. We can ship fast.
• How fast do you ship? We send orders within five days. We use FedEx, UPS, or DHL.
• Can I return it? Yes, you can return it within 30 days. It must be unused and in its original box.
• Which software works with it? You can use Unity Pro, Concept, or ProWORX 32. The 140DAI54300 works with all of them.
• What is the difference from 140DAI54000? The 140DAI54300 splits 16 inputs into two isolated groups. The 54000 has all 16 in one group.
• Is it safe in noisy factories? Yes, it passes tough EMC tests. It ignores electrical noise and static.
