140DAI54000 Schneider Electric 115V AC 16-Point Discrete Input Module

140DAI54000 Schneider Electric 115V AC 16‑Point Input Module

This 140DAI54000 from Schneider Electric works with Modicon Quantum systems. It handles 115 V AC signals. The module gives you 16 input points in one group. Bright LEDs show the status of each channel. This design makes wiring and checks simple.

Key Technical Facts

• Brand & Model: Schneider Electric 140DAI54000 – a genuine Modicon Quantum VAC input module.
• Voltage & Current: It runs on 115 V AC. The ON state starts at 79 V AC. OFF state is below 20 V AC. It draws 11.1 mA at 60 Hz.
• Speed & Frequency: It works with 47 to 63 Hz networks. Turn‑on time is 4.9 to 7.3 ms. Turn‑off time is 7.3 to 12.3 ms.
• Protection & Isolation: Channels are isolated to 1780 Vrms. Leakage current stays below 2.1 mA. It can handle 200 V for one cycle.
• Tough Environment: It works from 0 °C to 60 °C. It resists humidity up to 95 % without condensation. It also handles electrical noise and static shocks.
• Power & Size: It uses 180 mA from the bus. Max heat output is 5.5 W. The module is light, just 0.31 kg.
• LEDs & Safety: 16 green LEDs show input status. One green LED shows bus power. One red LED shows faults. It meets UL 508 and CSA standards.

Frequently Asked Questions

• Is this module new and real? Yes, we sell only 100 % genuine Schneider Electric 140DAI54000 modules. They come sealed from the factory.
• Do you have the 140DAI54000 in stock? Yes, we keep good stock of this 115 V AC module. We can ship fast.
• How fast do you ship? We send orders within five days. We use FedEx, UPS, or DHL.
• Can I return it? Yes, you can return it within 30 days. It must be unused and in its original box.
• Which software works with it? You can use Unity Pro, Concept, or ProWORX 32. The 140DAI54000 works with all of them.
• Is it safe in noisy factories? Yes, it passes tough EMC tests. It ignores electrical noise and static.
