140DAI45300 Schneider Electric 48V AC 32-Point Discrete Input Module

140DAI45300 Schneider Electric 48V AC 32‑Point Input Module

This 140DAI45300 from Schneider Electric works with Modicon Quantum systems. It handles 48 V AC signals. The module gives you 32 input points across four isolated groups. Bright LEDs show the status of each channel. This makes troubleshooting fast and easy.

Key Technical Facts

• Brand & Model: Schneider Electric 140DAI45300 – a genuine Modicon Quantum VAC input module.
• Voltage & Current: It runs on 48 V AC. The ON state starts at 29 V AC. OFF state is below 10 V AC. It draws 11.7 mA at 60 Hz.
• Speed & Frequency: It works with 47 to 63 Hz networks. Turn‑on time is 4.9 to 7.3 ms. Turn‑off time is 7.3 to 12.3 ms.
• Protection & Isolation: Groups are isolated to 1780 Vrms. Leakage current stays below 1.7 mA. It can handle 100 V for one cycle.
• Tough Environment: It works from 0 °C to 60 °C. It resists humidity up to 95 % without condensation. It also handles electrical noise and static shocks.
• Power & Size: It uses 250 mA from the bus. Max heat output is 10.9 W. The module is light, just 0.3 kg.
• LEDs & Safety: 32 green LEDs show input status. One green LED shows bus power. One red LED shows faults. It meets UL 508 and CSA standards.

Frequently Asked Questions

• Is this module new and real? Yes, we sell only 100 % genuine Schneider Electric 140DAI45300 modules. They come sealed from the factory.
• Do you have the 140DAI45300 in stock? Yes, we keep good stock of this 48 V AC module. We can ship fast.
• How fast do you ship? We send orders within five days. We use FedEx, UPS, or DHL.
• Can I return it? Yes, you can return it within 30 days. It must be unused and in its original box.
• Which software works with it? You can use Unity Pro, Concept, or ProWORX 32. The 140DAI45300 works with all of them.
• Is it safe in noisy factories? Yes, it passes tough EMC tests. It ignores electrical noise and static.
