140AVO02000 – Analog Output Module Schneider Electric

Schneider Electric Modicon Quantum 140AVO02000 Analog Output Module

Core Technical Specifications

• The 140AVO02000 module provides 4 independent analog outputs with clear per-channel status indication.
• It offers flexible output ranges: ±10V, ±5V, 0-10V, and 0-5V voltage, plus a -10 to 10 mA current range.
• The module features a 12-bit resolution for accurate output control.
• It achieves a fast output update time of just 3 milliseconds per module.
• The output setting time is a rapid 700 µs to within ±0.1% of the final value.
• Absolute accuracy at 25°C is ±0.15% of full scale.
• It provides strong isolation between channels and the bus (780V AC for 1 minute).

Electrical Ratings & Integration

• The module’s bus current requirement is 700 mA with a maximum dissipation of 4.5 Watts.
• It requires 4 output words in the Modicon Quantum controller’s I/O configuration.
• The associated fuse is a 0.063A, 250V, 3AG fast-blow type.
• Outputs drive loads with a source resistance of only 0.1 Ohm.
• Maximum recommended cable distance is 400 meters (1312 feet).

Environmental Durability & Certifications

• Designed for harsh conditions, it operates from 0 to 60°C (32 to 140°F).
• It resists electromagnetic interference up to 10 V/m (80-2000 MHz).
• The module functions reliably at altitudes up to 5000 meters (16404 feet).
• It carries critical industrial certifications: UL 508, cUL, CSA C22.2 No. 142, and FM Class 1 Div 2.

Packaging & Ordering Information

• Each 140AVO02000 is shipped as a new, factory-original unit in protective packaging.
• The single-unit package measures 31.5 x 16.5 x 5.0 cm and weighs approximately 467 grams.
• For fast delivery, we ship via global carriers like DHL, FedEx, or UPS.
• We stock this item and aim to process and ship orders within 5 business days.

Frequently Asked Questions (FAQ)

• What is the output resolution of the 140AVO02000?
  This module provides 12-bit resolution for its analog output signals.
• How many output channels does this module have?
  The Schneider Electric 140AVO02000 has 4 independent analog output channels.
• What is the module’s update speed?
  It features a very fast 3-millisecond update time for all channels.
• Is this item in stock and what is the delivery time?
  Yes, we have this module in stock. We typically ship within 5 business days via express services.
• What is your returns policy for this product?
  We offer a 30-day return policy for your peace of mind.
