140ACI03000 Analog Input Module Schneider Electric

Schneider Electric Modicon Quantum 8-Channel Analog Input Module

Key Technical Specifications

• Brand & Model: Schneider Electric 140ACI03000.
• Product Type: Analog input module for the Modicon Quantum series.
• Input Channels: The module has eight independent differential input channels.
• Measurement Ranges: It works with standard 4…20 mA current signals and 1…5 V voltage signals.
• Input Resolution: The device offers a clear and precise 12-bit signal resolution.
• Absolute Accuracy: Expect high accuracy within +/- 0.05% of the full measurement scale.
• Update Speed: The module updates all channel readings quickly within just 5 milliseconds.
• Input Protection: It can handle absolute maximum inputs up to 50 V DC and 25 mA safely.
• Noise Rejection: The module provides strong common mode rejection better than -72 dB at 60 Hz.
• Isolation Safety: It features 1000 V DC isolation between the field channels and the system bus.
• Wire Fault Detection: The module detects broken wires for 4-20 mA loops and under-voltage for 1-5 V signals.

Operational & Environmental Features

• Filtering: A built-in single-pole low-pass filter cuts off at 15 Hz for stable readings.
• Temperature Performance: Accuracy drift stays below 0.005% of full scale per degree Celsius.
• Operating Temperature: You can use this module in environments from 0°C to 60°C (32°F to 140°F).
• Storage Temperature: Store the unit safely in temperatures from -40°C to 85°C (-40°F to 185°F).
• Humidity Rating: It operates reliably at up to 95% relative humidity without condensation.
• High Altitude Use: The module is suitable for installation altitudes up to 5000 meters.
• EMC Robustness: It resists electrostatic discharge up to 8 kV air and 4 kV contact per standards.
• Power Consumption: The bus current requirement is 240 mA with a power dissipation of 2 watts.

Physical Design & Indicators

• Module Format: This is a standard format Quantum series I/O module.
• Status LEDs: A green LED shows active bus communication and a red LED indicates external faults.
• Channel LEDs: Each of the eight channels has separate green (ON) and red (FAULT) indicator lights.
• Product Weight: The module net weight is only 0.3 kilograms (0.7 pounds).

Packaging & Shipping Details

• Package Contents: You will receive one (1) brand new, genuine 140ACI03000 module in its original packaging.
• Package Dimensions: The box measures 31.0 cm L x 16.5 cm W x 4.8 cm H (12.2″ x 6.5″ x 1.89″).
• Shipping Weight: The total package weight for shipping is approximately 450 grams (15.9 ounces).
• Shipping Methods: We ship worldwide using reliable carriers like FedEx, UPS, and DHL.

Frequently Asked Questions (FAQ)

• Is this module brand new and original?
  Yes, we supply only 100% brand new and original Schneider Electric modules.
• What signals does the 140ACI03000 accept?
  It accepts both 4-20 mA current loop signals and 1-5 V voltage signals on its eight channels.
• How fast does the module read the inputs?
  The module updates readings for all eight channels every 5 milliseconds.
• Do you have this item in stock?
  We typically maintain stock of this popular Modicon Quantum module for fast delivery.
• How quickly will my order ship?
  We process and ship orders within 5 business days after payment confirmation.
• What is your return policy?
  We offer a 30-day return period for items in new and unused condition.
